SOLAR-2RTM

Standalone auxiliary reader with keypad for 2 doors

Ref: F0101000093

This auxiliary reader offers the flexibility of both proximity credentials and keypad codes. Administrators can decide whether users must present a card, input a PIN, or do both in order to gain access. This reader works in combination with the SOLAR-2R controller to create a simple and effective 2-door access control solution.

Scroll to learn more

Key features

  • Auxiliary reader for SOLAR-2R standalone controller

  • Creates a simple and effective 2-door system

  • Audible and visual feedback

  • Soft backlighting with touch-sensitive keypad

  • Choose between card only, PIN only, or card+PIN access

Downloads & links

Features

  • Technical specifications

    • Technology
      125kHz proximity
    • User Limit
      Up to 1000 cards/codes
    • Number of Relays
      2
    • Mounting
      Surface
    • Min Temperature (°C)
      -30°C
    • Max Temperature (°C)
      70°C
    • Frequency
      125kHz
  • Electrical specifications

    • Min. Voltage (V)
      12Vdc
    • Voltage AC/DC
      DC
    • Max Power Consumption (mA)
      200mA
  • Certifications

    • IP Rating
      IP53
    • IK Rating
      IK10
  • Appearance

    • Surface Material
      Polycarbonate
    • Colour
      Black
  • Dimensions

    • Product Height (mm)
      130
    • Product Width (mm)
      90
    • Product Depth (mm)
      28
    • Product Weight (kg)
      0.3
